Description The FR9832 is a synchronous step-down DC/DC converter that provides wide 6V to 32V input voltage range. There are two packages, SOP-8 & SOP-8 (Exposed Pad), to support 2A continuous output current. The FR9832 fault protection includes cycle-by-cycle current limit, input UVLO, output over voltage protection and thermal shutdown. Besides, adjustable soft-start function prevents inrush current at turn-on. This device uses current mode control scheme which provides fast transient response. Internal compensation function reduces external compensation components and simplifies the design process. In shutdown mode, the supply current is less than 1μA. The FR9832 is available in SOP-8 and SOP-8 (exposed pad) packages. It is RoHS compliant and 100% lead (Pb) free. |
|
Features Low R DS(ON) Integrated Power MOSFET (130mΩ/110mΩ) Wide Input Voltage Range: 6V to 32V Adjustable Output Voltage from 0.925V to 16V 2A Output Current Fixed 340kHz Switching Frequency Current Mode Operation Internal Compensation Function Adjustable Soft-Start Cycle-by-Cycle Current Limit Input Under Voltage Lockout Over Voltage Protection Over Temperature Protection with Auto Recovery SOP-8 and SOP-8 Exposed Pad Packages |
|
Applications Car Charger LCD Display, TV Distributed Power System Networking, XDSL Modem |
