代理FP6378A降压高效率3A芯片
详情
|
Description The FP6378A is a high efficiency, high frequency synchronous DC-DC step-down regulator. The 100% duty cycle feature provides low dropout operation, extending battery life in portable systems. The internal synchronous switch increases efficiency and eliminates the need for external Schottky diode. At shutdown mode, the input supply current is less than 1µA. The current limit protection and on-chip thermal shutdown features provide protection against any combination of overload or ambient temperature. |
代理商：深圳市夸克微科技 郑先生 ：13528458039 QQ 2867714804
FP6378A 规格书下载 - [ 芯片模块网，www.icmkw.com 规格书，PCB文件，模块板资料网站，让芯片更简单】
|
Features Low R DS(ON) for Internal Switch (Top/Bottom):180/100mΩ 2.5V~5.5V Input Voltage Range 2A Output Current 1MHz Switching Frequency Minimizes the External Components Internal Soft-Start Limits the Inrush Current Internal Compensation Function 100% Dropout Operation Power Good Indicator Output (SOT-23-6 only) RoHS Compliant and Halogen Free SOT-23-5 and SOT-23-6 Packages |
|
Applications Set Top Box LCD TV Tablet Portable Equipment |
